| Part Number | AJ65SBTB2-8T |
| Number of output points | 8 points |
| Insulation method | Relay |
| Rated load voltage×current | 24 V DC (resistive load), 240 V AC (cosf = 1)/ |
| 2 A/point 4 A/common |
| Min. switching load | 5 V DC 1 mA |
| Max. switching voltage | 264 V AC 125 V DC |
| Max. switching frequency | 3600 times/hour |
| Surge suppression | None |
| Common method | 8 points/1 common (terminal block 2-wire type) |
| Number of stations | 1 station 32 points assignment (use 8 points) |
| occupied |
| Noise durability | Simulator noise 1500 Vp-p, noise width 1 ms, noise carrier |
| frequency 25 to 60 Hz (noise simulator condition) Fast transient/noise burst IEC61000-4-4 : 1 kV |
| Withstand voltage | 2830 V AC between all AC external terminals and ground, |
| rms/ 3 cycles (2000 m above sea level) |
| 500 V AC for 1 minutes between all DC external terminals and ground |
| Insulation resistance | 10 M W or higher, measured with a 500 V DC insulation resistance |
| tester between all AC external terminals and ground |
| 10 M W or higher, measured with a 500 V DC insulation resistance tester between all DC external terminals and ground |
| Weight (kg) (lb.) | 0.25 (0.55) |
|
|
| Part Number | AJ65SBTB2-16T |
| Number of output points | 16 points |
| Insulation method | Photocoupler |
| Rated load voltage | 12/24 V DC |
| Operating load voltage range | 10.2 to 26.4 V DC (ripple ratio: within 5 %) |
| Max. load current | 0.5 A/point (when all point is ON: 0.22 A/point) |
| 3.6 A/1 common |
| Max. inrush current | 1.0 A 10 ms or lower |
| Leakage current at OFF | 0.25 mA or lower |
| Voltage drop at ON | 0.3 V or lower (TYP) 0.5 A |
| 0.6 V or lower (MAX) 0.5 A |
| Surge suppression | Zener diode |
| Common wiring method | 16 points/1 common (terminal block 2-wire type) |
| Occupied station number | 1 station 32 points assignment |
| (use 16 points) |
| Noise durability | DC type noise voltage 500 Vp-p, noise width 1 ms, noise carrier frequency 25 to 60 Hz (noise simulator condition) |
| Withstand voltage | 500 V AC for 1 minute between all DC external terminals and |
| ground |
| Insulation resistance | 10 MW or higher, measured with a 500 V DC insulation resistance tester |
| Weight (kg) | 0.25 |
| External wiring system | 7-point 2-piece terminal block (transmission circuit, module power supply terminal), Direct-type 34-point terminal block (I/O power supply area) (M3 screw) |
| Applicable solderless terminal | • RAV1.25-3.5 (in conformance with JIS C 2805) [Applicable wire size: 0.3 to1.25 mm2] |
| • V2-MS3 (Japan Solderless Terminal Mfg. Co., Ltd.), RAP2-3S RAP2-3SL (Japan Terminal Co., Ltd.) |
| 2-3N, 2-3S (NICHIFU TERMINAL INDUSTRIES Co., Ltd.) |
| [Applicable wire size: 1.25 to 2 mm2] |
| Accessory | User’s Manual |
|
|
