| Dimensions (W x H x D) | 80 mm x 30.4 mm x 64 mm |
| Sensing distance | 9 mm |
| Sensing distance tolerance | ± 2 mm |
| Housing design (light emission) | Rectangular |
| Light source | LED, Red, green 1) |
| Wave length | 560 nm |
| Light emission | Long and short side of housing, exchangeable |
| Light spot size | Ø 2.5 mm |
| Light spot direction | Round 2) |
| Pull-up/Pull-down resistor | 22 k OHM 3) |
| Adjustment | Potentiometer |
|
|
| Supply voltage | 10 V DC … 30 V DC |
| Ripple | ≤ 5 Vpp |
| Power consumption | < 80 mA 1) |
| Switching frequency | 5 kHz 2) |
| Response time | > 100 µs 3) |
| Switching output | NPN |
| Switching output (voltage) | NPN: HIGH = approx. VS / LOW ≤ 2 V |
| Analog output | 0.15 V … 6 V 4) |
| Output current Imax. | 200 mA |
| Connection type | Cable with male connector, 2 m 5) |
| Circuit protection | UV connections, reverse polarity protected |
| Output Q short-circuit protected |
| Interference pulse suppression |
| Enclosure rating | IP67 |
| Housing material | Metal, Zinc diecast |
