| Housing | Cylindrical thread design |
| Housing | Standard |
| Thread size | M30 x 1.5 |
| Diameter | Ø 30 mm |
| Sensing range Sn | 15 mm |
| Installation type | Non-flush |
| Switching frequency | 25 Hz 1) |
| 30 Hz 2) |
| Connection type | Cable, 2-wire, 2 m |
| Output function | NO |
| Electrical wiring | AC/DC 2-wire |
| Enclosure rating | IP67 3) |
| Special characteristic | Series connectable |
| Supply voltage | 20 V AC/DC … 250 V AC/DC |
| Voltage drop | ≤ 6.5 V |
| Time delay before availability | ≤ 8 ms |
| Hysteresis | 1 % … 15 % |
| Reproducibility | ≤ 10 % 1) 2) 3) |
| Temperature drift (of Sr) | ± 10 % |
| EMC | According to EN 60947-5-2 |
| As per EN 55011, class B |
| Continuous current Ia | ≤ 200 mA |
| Off-state current | ≤ 4 mA |
| Minimum load current | ≥ 5 mA |
| Short-time withstand current | 2.2 A 4) |
| Cable material | PVC |
| Conductor size | 0.5 mm² |
| Short-circuit protection | – 5) |
| Power-up pulse protection | ✔ |
| Shock and vibration resistance | 30 g, 11 ms / 10 … 55 Hz, 1 mm |
| Ambient operating temperature | –25 °C … +70 °C |
| Housing material | Brass, nickel-plated |
| Sensing face material | Plastic, PBT |
| Housing length | 81 mm |
| Thread length | 44 mm |
| Tightening torque, max. | ≤ 50 Nm |
| Items supplied | Mounting nut, brass, nickel-plated (2x) |
| Protection class | II |
| Rated insulation voltage Ui | 250 V AC |
| Usage category | AC-140 6) |
| DC-13 7) |
| Contamination rating | 3 |
| Rated impulse withstand voltage | 4 kV |
