| Mitsubishi Touch screen HMIs | Model Number | Screen Size | Resolution | Display Type | Frame Color | Power Supply | Stk. Item |
| GT2310 | GT2310-VTBA | 10.4″ | VGA (640 x 480) |
| Black | 100-240VAC | S |
| GT2310 | GT2310-VTBD | TFT Color | 24VDC | S |
| GT2308 | GT2308-VTBA | 8.4″ | VGA (640 x 480) |
| Black | 100-240VAC | S |
| GT2308 | GT2308-VTBD |
| 24VDC | S |
| 10.4″ Mitsubishi Touch screen HMIs | GT2310-VTBA | GT2308-VTBA | GT2310-VTBD | GT2308-VTBD |
| Input Power Supply Voltage | 100 to 240VAC (+10%, -15%) | 24VDC (+25%, -20%) |
| Input Power Supply Frequency | 50/60Hz ±5% | – |
| Maximum Load | 18W or less | 11W or less | 16W or less | 11W or less |
| Stand Alone | 15W | 9W | 13W | 8W |
| Stand Alone with Backlight Off | 8W | 6W | 7W | 6W |
| Inrush Current | 40A or less (4ms, ambient temperature 25°C, maximum load) | 40A or less (2ms, ambient temperature 25°C, maximum load) |
| Permissible Instantaneous Failure Time | Within 20ms (100VAC or more) | Within 10ms |
| Noise Resistance | Noise voltage 1500Vp-p, noise width 1μs by noise simulator with noise frequency 25 to 60Hz | Noise voltage 500Vp-p, noise width 1μs by noise simulator with noise frequency 25 to 60Hz |
| Withstand Voltage | 1500VAC for 1 minute between power supply terminal and ground | 350VAC for 1 minute between power supply terminal and ground |
| Insulation Resistance | 10MΩ or higher with an insulation resistance tester (500VDC between power supply terminal and ground) |
| Applicable Wire Size | 0.75 to 2 [mm²] |
| Clamp Terminal | Clamp terminals for M3 screw RAV1.25-3, V2-S3.3, V2-N3A, FV2-N3A |
| Tightening Torque (Terminal Block’s Terminal Screws) | 0.5 to 0.8 [N·m] |
| 10.4″ Mitsubishi Touch screen HMIs | GT2310-VTBA • GT2310-VTBD | GT2308-VTBA • GT2308-VTBD |
| TFT color LCD |
| Type |
| Screen Size | 10.4″ | 8.4″ |
| Resolution (Dots) | 640 x 480 VGA |
| Display Size (W x H) mm | 211.2 x 158.4 | 170.9 x 128.2 |
| Number of Characters | 16-dot standard font: 40 chars. x 30 lines (2-byte); 12-dot standard font: 53 chars. x 40 lines (2-byte) |
| Display Colors | 65536 colors |
| Intensity Adjustment | 16-level adjustment |
| Backlight Type | LED (not replaceable) |
| Life (*4) | Approx. 50000 hours or more (Time for display intensity reaches 50% at ambient temperature of 25°C) |
| Type | Analog resistive film |
| Key Size (Dots) | Minimum 2 x 2 dots (per key) (*7) |
| Simultaneous Press | Not available (only 1 point can be pressed) (*5) |
| Life | 1 million times or more (operating force 0.98N or less) |
| Panel Color | Black |
| Memory User Memory Capacity | Memory for storage (ROM): 9MB, Memory for operation (RAM): 9MB |
| Life (No. of Writings) | 100,000 times |
| Internal Clock Accuracy | ±90 sec/month (ambient temperature 25°C) |
| Buzzer Output | Single tone (tone, tone length adjustable) |
| Power LED | Emission color: 2 colors (blue, orange) |
| Protective Construction | Front: IP67F (*6, *8) In control panel: IP2X |
| External Dimensions (W x H x D) mm | 303 x 218 x 56 | 241 x 194 x 56 |
| Panel Cutout (W x H) mm | 289 x 200 | 227 x 176 |
| Weight (Excluding Mounting Brackets) | 1.9 kg | 1.5 kg |
| Applicable Software Package | GT Works3 Version1.100E or later |
|
|
|
|
|
|
|
|
|
|
|
