| Type | Stand-alone |
| Dimensions (W x H x D) | 10.5 mm x 34.6 mm x 71.9 mm |
| Housing design (light emission) | Rectangular |
| Sensing range max. | 0 m … 20 m, Through-beam system 1) 2) |
| Sensing range | 0 mm … 1,400 mm, Proximity system 3) 4) |
| 0 … 18 m, Through-beam system 1) 2) |
| Focus | 5) |
| Type of light | Visible red light |
| Light source | LED 6) |
| Angle of dispersion | Approx. 65° 5) |
| Wave length | 650 nm |
| Adjustment | Menu-controlled |
| Single teach-in button |
| Cable |
| Delay time | Programmable, 0 ms … 9,999 ms |
| Time functions | Without time delay |
| Off delay |
| On delay |
| ON and OFF delay |
| One shot |
| Indication | Display |
| Display | LED status display / 2x 4-character digital dual displays, Set value (green indicator) and actual value (red indicator) are displayed simultaneously, display of parameters |
|
|
| Supply voltage | 12 V DC … 24 V DC 1) |
| Ripple | ≤ 10 % 2) |
| Power consumption | 50 mA 3) |
| Switching output | PNP |
| Number of switching outputs | 1 |
| Switching mode | Light/dark switching |
| Switching mode selector | Manually selectable |
| Output current Imax. | ≤ 100 mA |
| Response time | ≤ 16 µs, ≤ 70 µs, ≤ 250 µs, ≤ 2,000 µs, ≤ 8,000 µs 4) |
| Switching frequency | 31.2 kHz |
| 7.1 kHz |
| 2 kHz |
| 250 Hz |
| 62.5 Hz |
| Time functions | Without time delay |
| Off delay |
| On delay |
| ON and OFF delay |
| One shot |
| Delay time | Programmable, 0 ms … 9,999 ms |
| Input | Multifunctional input MF |
| Connection type | Cable, 4-wire, 2 m 5) |
| Cable material | PVC |
| Conductor cross-section | 0.2 mm² |
| Circuit protection | A 6) |
| B 7) |
| C 8) |
| D 9) |
| Protection class | III |
| Weight | 25 g |
| Housing material | Plastic, ABS/PC |
| Enclosure rating | IP50 10) |
| Items supplied | BEF-WLL180 mounting bracket |
| Ambient operating temperature | –25 °C … +55 °C |
| Ambient storage temperature | –40 °C … +70 °C |
| UL File No. | NRKH.E300503 |
